| CLASS | FVZ34UL – PDS (Dump) | FVZ34UL - TDS |
| Drive system | 6x4 | 6x4 |
| DIMENSION (mm) | ||
| Overall dimension (OALxOWxOH) | 7,605 x 2,400 x 2,870 | 9,730 x 2,400 x 2,870 |
| Front & Rear Tread (AW/CW) | 2,445/1,850 | 2,445/1,850 |
| Wheel Base (WB) | 5,060 | 6,350 |
| Cap to End of chassis (CE) | 5,335 | 7,660 |
| WEIGHT (kg) | ||
| Gross Vehicle Weight | 25,000 kg | |
| Kerb Weight (Cab & Chassis) | 7,060 kg | 7,305 kg |
| Maximum Payload (Approximate)** | ~ 13,000 kg - 14,000 kg | |
| Fuel Tank Capacity | 200 L | |
| ENGINE - TRANSMISSION | ||
| Engine Model | 6HK1-TCS | |
| Engine Type | Direct Injection , OHC intercooled turbo | |
| Displacement | 7,790 cc | |
| Max. Output PS (kW)/rpm | 280(206)/2,400 | |
| Max. Torque N.m(kg.m)/rpm | 882(90)/1,450 | |
| Transmission Type | 9-Speed Transmission | |
| BASIC SYSTEM | ||
| Steering System | Recirculating ball nut type with integral power assist system | |
| Brake System | Full-air dual circuit Wedge type, leading-trailing on front and rear wheels | |
| Battery | 24V (12Vx2) | |
| Generator | 24V-50A (1.2kW) | |
(Note: ** Maximum payload depends on rear body application weight)
